The DRM VER Doctoring Rewinding Machine is differentiated from other coil rewinding machines in having a unique vertical layout, with the unwind and rewind on the same side, enabling the operator to load/ unload, monitor and control from one position.
Technical Specification
| Maximum web width | 600 mm (up to 800 mm on request) |
| Unwind core inner diameter | 76 mm and 152 mm |
| Maximum unwind diameter | 600 mm (up to 800 mm on request) |
| Rewind core inner diameter | 76 mm and 152 mm |
| Maximum rewind diameter | 600 mm (up to 800 mm on request) |
| Materials handled | Plastic films and flexible packaging laminates (paper and foil-based laminates on request) |
| Speed | 600 mpm (800 mpm on request) |
Optional Features
| Edge trimming (Razor in air) and trim extraction | |
| Full width stroboscope | |
| Interchangeable air shaft for 152 mm ID core | |
| Pneumatically operated reel loader/ off-loader |
